1964 - 1967, All Markets
| Colour | Fuse | Components |
| black | none | earth |
| black/green | green | wiper switch wiper motor 'normal' speed |
| blue | none | main lighting switch dipswitch |
| blue/red | none | dipswitch headlamp dipped beams |
| blue/white | none | dipswitch headlamp flasher switch 'main beam' warning light headlamp main beams |
| brown | none | solenoid ignition switch fusebox main lighting switch headlamp flasher switch cigar lighter dynamo control box |
| brown/green | none | dynamo control box |
| brown/yellow | none | dynamo control box ignition warning light |
| green | green | fusebox brake light switch indicator flasher heater fan switch wiper motor voltage stabiliser reverse light switch |
| green/black | green | fuel gauge fuel tank sender |
| green/brown 1 | green | heater fan switch heater fan |
| green/brown 2 | green | reverse lights switch reverse lights |
| green/purple | green | brake light switch brake lights |
| green/red | green | indicator-signal switch left-side flashers |
| green/white | green | indicator-signal switch right-side flashers |
| light-green | green | wiper switch wiper motor 'fast' speed |
| light-green/blue | green | indicator-signal switch right-side flasher repeater |
| light-green/brown | green | indicator flasher indicator switch |
| light-green/green | green | voltage stabiliser fuel gauge |
| light-green/purple | green | indicator flasher indicator repeater lamps |
| light-green/yellow | green | indicator switch left indicator repeater lamp |
| purple | purple | fusebox horns |
| purple/black | purple | horn switch horns |
| red | none | main lighting switch rear/parking lights panel lights dimmer map light switch |
| red/green | none | map light switch map light |
| red/white | none | panel lights dimmer panel lights |
| white | none | ignition switch ignition warning light fusebox tachometer (12v) via tachometer pick-up to coil SW fuel pump overdrive relay overdrive manual switch heated rear window fuse |
| white/black | none | coil CB distributor |
| white/red | none | ignition switch starter solenoid |
| yellow | none | overdrive manual
switch overdrive relay overdrive vacuum switch |
| yellow/purple | none | overdrive gearbox
switch overdrive solenoid |
| yellow/red | none | overdrive vacuum
switch overdrive relay overdrive gearbox switch |
